SCT-013-000 50mA 30A Switching Current Transformer sensor

KSh 1,500.00

Only 1 left in stock

Description
Reviews (0)

The SCT-013-000 30A/1V Switching Current Transformer is a non-invasive AC current sensor designed for safe and accurate measurement of electrical current without the need to cut or modify existing wiring. Using a clamp-on split-core design, it easily clips around a live conductor to detect current flow and convert it into a proportional voltage signal that can be read by microcontrollers such as Arduino, ESP32, or other monitoring systems.

This sensor is widely used in energy monitoring, power measurement, smart home systems, and IoT energy projects. Its compact design and insulated casing make it safe, reliable, and easy to install in both prototyping and permanent monitoring setups.

Key Features

Non-invasive measurement – No need to cut wires; simply clamp around the conductor

Maximum current sensing: up to 30A AC

Output signal: 0–1V AC proportional to the measured current

High accuracy and stability for energy monitoring applications

Split-core clamp design for quick and easy installation

Good electrical isolation for safe operation

Compatible with Arduino, ESP32, Raspberry Pi, and other microcontrollers

Typical Applications

Home and industrial energy monitoring systems

IoT power consumption tracking

Smart meters and energy dashboards

Appliance power monitoring

Solar power monitoring systems

Electrical load analysis

Technical Specifications

Model: SCT-013-000

Rated Input Current: 0–30A AC

Output Voltage: 0–1V AC

Core Type: Split-core clamp

Operating Frequency: 50–60 Hz

Insulation: High insulation safety design

Cable Length: ~1 meter

Connector: 3.5 mm audio jack

Package Includes

1 × SCT-013-000 30A/1V Current Transformer Sensor

This sensor is an excellent choice for engineers, students, and IoT developers who want a simple and safe way to measure AC current in real-time power monitoring projects.
