XL6009 DC-DC Adjustable Boost Module

The XL6009 DC-DC Adjustable Boost Module is a versatile power supply component that can increase (step up) a low input voltage to a higher output voltage. It’s a popular choice for various electronic projects and applications due to its efficiency and flexibility.

Description:

• Adjustable Output Voltage: Allows you to set the desired output voltage within a specified range.
• High Efficiency: Converts input power to output power with minimal energy loss, ensuring efficient operation.
• Small Size: Compact design makes it suitable for various projects and applications.
• Easy to Use: Simple connections and minimal external components required.
• Wide Input Voltage Range: Can operate with a wide range of input voltages.

Specifications:

• Input Voltage: Typically 3V to 32V (may vary depending on specific module)
• Output Voltage: Adjustable from 3.5V to 35V (or higher, depending on the module)
• Output Current: Varies based on the module and input/output voltage. Can typically handle up to 4A
• Efficiency: Generally around 90-95% (can vary depending on operating conditions)
• Switching Frequency: High-frequency switching for efficient operation
• Operating Temperature: -40°C to +85°C
• Dimensions: Small, typically around 1.5cm x 1.5cm (may vary)

Applications:

• Battery-Powered Devices: Boosting the voltage from a battery to power devices that require a higher voltage.
• LED Lighting: Driving high-power LEDs with a higher voltage than the battery can provide.
• Portable Electronics: Powering devices that require a higher voltage than the available input source.
• Experimental Projects: Creating custom power supplies for various electronic projects.

Key Features:

• Adjustable Output Voltage: Tailors the output voltage to your specific needs.
• High Efficiency: Minimizes energy loss for optimal performance.
• Compact Size: Suitable for space-constrained applications.
• Easy to Use: Simple connections and minimal external components.
• Versatile: Can be used in a wide range of applications.

The XL6009 DC-DC Adjustable Boost Module is a valuable tool for electronics enthusiasts and professionals who need to increase the voltage of a power source. Its adjustable output voltage, high efficiency, and compact size make it a popular choice for various projects and applications.
