11.1 V 2200mAH Lipo Battery

specifications

Capacity: 2200mAh (milliampere-hours)

Voltage: 11.1V (volts)

Chemistry: Lithium Polymer (LiPo)

Configuration: 3S (3 cells in series)

Charging Voltage: 12.6V (maximum)

Discharge Rate: Varies depending on the battery’s C rating (e.g., 25C, 35C, etc.)

Dimensions: Approximately 100 x 35 x 25 mm (may vary depending on the manufacturer)

Weight: Approximately 150 grams (may vary depending on the manufacturer)

Additional Specifications:

* Connector: XT60, JST, or other connector type (may vary depending on the manufacturer)

* Balance Connector: JST-XH or similar balance connector for charging and monitoring individual cells

* Storage Voltage: 3.8V per cell (11.4V total)

* Operating Temperature: 0°C to 60°C

* Safety Features: Built-in protection circuit (PCB) to prevent overcharging, over-discharging, short circuit, and thermal runaway

Important Note:

The discharge rate of a LiPo battery is expressed in terms of its C rating. For example, a 2200mAh battery with a 25C discharge rate can continuously deliver 25C x 2200mAh = 55 amps of current. Higher C ratings allow for higher discharge currents, but they also come with increased heat and reduced cycle life.
